Manual Keg Washer And Filler

Keg washing and filling are two of the most important steps in brewery packaging. A reliable keg washing and filling machine helps breweries clean kegs thoroughly, fill them accurately, and maintain beer quality and carbonation.

This manual keg washing and filling machine is designed for Nano breweries, microbreweries, and commercial breweries that need efficient keg processing. It combines keg washing and keg filling in one unit, with PLC control and adjustable parameters.

The machine is built with a SUS304 main body and a SUS304 pump head. It supports EURO, DIN, and US standard kegs from 20L to 60L, with A/S/D/G spear types.

Working Process

Lock down → Air purge / drain off → Hot water washing → Air purge / drain off → Caustic washing → Air purge / to caustic tank → Hot water 1 washing → Air purge / drain off → Hot water 2 washing → Air purge / drain off → Sanitizer sterilize → CO2 purge / to sanitizer tank → CO2 fill

Filling Procedure

Lock → CO2 fill → Filling → Stop

Technical Specifications

Machine Type: Automatic keg washing and filling machine Size (W×L×H): 125 × 140 × 159 cm Weight: 223 kg With Slide: No Packing Size (L×W×H): 165 × 141 × 228 cm Gross Weight: 400 kg Capacity: Washing part: 40–50 kegs/h; Filling part: 40–50 kegs/h Power: According to user local power (3 phases 380V 50Hz) Power Port: 3P+N+G Heater Way: Options: steam coiler or electrical heater Power Consumption: 2KW or 15.5KW Main Material: SUS304 Water Tank Material and Volume: Single tank / Volume = 100L (2 tanks available) Motor Type and Brand: SUS304 pump head Temperature Probe: NTC Temperature Control Mode: STC-200 or Korea Autonics TCN4M Time Setting: Siemens PLC 200 Smart Connection Type:

• Water inlet and drain outlet: 1.5" Tri-clamp
• Steam inlet: DIN male fitting Spear Type: A/S/D/G Keg Type: EURO, DIN, US standard 20L–60L keg Filling Measurement Type: Flow switch Washing Part Inlet with Pressure Detection: No Washing Part Outlet with Residual Liquid Detection: Yes Package: Non-fumigating wooden cases Lead Time: 40–45 days

*Specifications may vary depending on configuration. Please contact us for detailed parameters.

Applications

• Nano breweries
• Microbreweries
• Brewpubs
• Commercial breweries
• Keg cleaning and filling workshops
• 20L–60L keg processing

Why Choose This Manual Keg Washer And Filler?

For breweries that package beer in kegs, washing and filling are daily operations. A good keg washing and filling machine should clean kegs thoroughly, fill them accurately, and protect beer carbonation.

This manual keg washing and filling machine supports EURO, DIN, and US standard kegs, making it a practical choice for breweries that need flexible keg processing.
